Windows and Doors
In the welded-frame range the outer frame, sub-frame, screen sash and glazed sash are laser welded into a single body. There is no mitred joint filled with a corner cleat, which is the detail that opens up and starts to leak on a conventionally assembled frame after a few years.
Visual reference
| Specifications | |
|---|---|
| Series | 115 and 122 series, welded frame |
| Profile | Aluminium 6060-T66 |
| Wall thickness | 1.4 mm / 1.8 mm / 2.0 mm, selected by series and load case |
| Glazing | Tempered as standard; insulating, Low-E, laminated and triple options on request |
| Opening | Casement, tilt-and-turn |
| Sealing | Welded gasket, thermal break strip and weather seal |
| Hardware | Hardware selected by series, to be confirmed per order |
| Finish | Full-frame powder coating, one batch per order |
Values are typical for this product family. Final specification is confirmed on the drawing for each order.
Product photos and reference views.
Other items in this range.
Two inward-opening leaves for easier cleaning and safer high-rise use.
Vertical lift travel that keeps the opening clear of furniture and walkways.
The same vertical travel in a smaller frame for bedrooms and studies.
Tell us the product, the sizes and the destination port. Drawings, photographs and specification sheets are welcome.
